Traslapo Movil Pvc Profiles Americano Linea Pvc

Lumei Americano Linea uPVC profile adopts environmental protection formula selects non-toxic CaZn heat stabilizer, imported BASF titanium dioxide, ultraviolet absorber, antioxidant agent and other top-quality additives. Those help all properties of Lumei uPVC profiles accomplices with the Chinese National Energy Conservation and Environmental Protection Indicators as well as the EU market Standards. Lumei PVC profiles complied with the national standards GB / T8814-2004 and strictly follow ISO9001-2008 international quality management systems and passed the weather resistance test of 6000 hours. Lumei focuses on serving the international market whose profiles obtained CE & RoHS certification.

Quantity:

Traslapo movil pvc profiles americano linea pvc


In order to meet the customer's demand of the American market, Lumei PVC Americano Linea independently developed and designed American Linea LM-5000 series sliding window profiles and American Linea LM-8000 series sliding door (PVC Patio Door) profiles, specially focusing on and serving customers in the Americas.

    Lumei Americano Linea uPVC profile adopts environmental protection formula selects non-toxic CaZn heat stabilizer, imported BASF titanium dioxide, ultraviolet absorber, antioxidant agent and other top-quality additives. Those help all properties of Lumei uPVC profiles accomplices with the Chinese National Energy Conservation and Environmental Protection Indicators as well as the EU market Standards. Lumei PVC profiles complied with the national standards GB / T8814-2004 and strictly follow ISO9001-2008 international quality management systems and passed the weather resistance test of 6000 hours. Lumei PVC Americano Linea focuses on serving the international market whose profiles obtained CE & RoHS certification.


traslapo movil pvc profiles americano linea pvc


traslapo movil pvc profiles americano linea pvc



Product Features


The difference between American and European linea is the structure of sliding windows.

The uPVC sliding sash of the European line window slides on the tracks of the PVC frame, that is, the sliding sash surrounding frame structure. Its seal is formed by the top of the inner side of the sliding sashes and the two sides of the guide rail. The sash of the American sliding window slides in the groove of the sliding frame (that is, the frame surrounding sash structure), and a separate guide rail can be installed in the groove, or it can slide directly on the bottom of the groove. The sealing of American windows is realized by the tops between the outer side of the sliding sash and the two sides of the groove. The tops can be installed on the sliding sashes or on the side wall of the groove on the sliding frame. Comparison of the two structures It can be seen that the latter one has better water and air tightness property. For this reason, people have made targeted improvements on European-style sliding windows-adding a sealing guide rail between the two sliding sashes to impro ve the watertight and air tightness of the entire window.


traslapo movil pvc profiles americano linea pvc


The sashes of European-style sliding windows are welded with the same profile. After welding, the shape of the whole sash is uniform and the shape is neat and tight. The sashes of American sliding windows are usually composed of two or more profiles which are either welded or screwed. Various sashes have their own functions. Some sashes directly design with the push-pull (or lift) handle on the top; some sashes directly design with the function of the cover plate, thereby eliminating the cover plate profile; for some sashes on the bottom there is a groove for installing the pulley.


traslapo movil pvc profiles americano linea pvc

traslapo movil pvc profiles americano linea pvc



Products Paymet& Packaging&Loading


A. T/T & L/C

B. Within 15 days after receiving 50% deposit of T/T

C.Plastic bags as customers' requirements

D.Samples can be provided freely to test our products quality

E.The usual container : 20GP ( can load 8-11 tons ,the delivery time about 7-10 days)

 40 HQ(can load 24-26 tons,the delivery time about 10-15 days)


Sliding Windows Profiles UPVC Sliding Profiles for Doors


FAQ


Q: Are you trading company or manufacturer ?

A: We are factory.

Q: How long is your delivery time?

A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.

Q: Do you provide samples ? is it free or extra ?

A: Yes, we could offer the sample for free charge but do not pay the cost of freight.

Q: How to order?

A:Please send us your purchase order by Email or Fax, We need to know the following information for your order:

1) Product information: Order Quantity, Specification(size ,material, color, length, Design styles),

Artwork or Sample will be the best.

2) Delivery time required.

3) Shipping information: Address, Phone number, Destination seaport/airport.

4) Forwarder's contact details if there is any in China.

5. Q: What is the payment terms of order amount?

A:We accept T/T or L/C at sight.

6. Q: Can I put the logo or company name on the products ?

A:Sure. We will follow your request to produce your personal brand profiles.
